Product Details:
Payment & Shipping Terms:
|
| After-sales Service Provided: | Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support, Engineers Available To Service Machinery Overseas | Application: | Powder |
|---|---|---|---|
| Process Line: | Foodstuff, Chemical And Pharmaceutical | Type: | Extractor |
| Fineness Powder: | 20-120 Mesh | Name: | Dust Collecting Food Flour Crusher Machine With Dust Collector |
| Material: | SUS304/316L | Keywords: | Grinder Machine |
| High Light: | powder grinding machine,pharmaceutical powder grinder |
||
Dust Collecting Food flour Crusher with fine powder gringding machine
Specifications
1, 40-150 mesh
2, stainless steel
3, main engini, buit-in centrifugal grading centrugal systerm
4, suit dry plant and chin
Main Application :
The machine unit is suitable for such fields as pharmaceutical, food, chemical etc.. With no limit of viscosity, hardness, and fiber content of the material, it is functioned with air cooling, screen-free ,etc.. It has good pulverization effect to any material, especially suitable for fiberous Chinese herbs or oily materials.
Working Principle:
The machine unit is made up of charging bucket, stepped gear, pulverizing knife, gearring, pulverizing motor, discharging port, fan blade, aggregating box, dust collection box etc.. The material is fed into the pulverizing room through the charging bucket, and pulverized by knife with high rotation. The fineness of the material is controlled by the adjustment of the gap between stepped gear and stepped pan. The well-processed material is suctioned from the pulverizing room to the hop-pocket in the aggregating box by fan blade with high rotation, while the half-processed material will remain to be pulverized in the pulverizing room. The dust in the hop-pocket is collected by the dust collection box. The machine unit is designed according to GMP standard. It is featured with simple structure, convenient operation and cleaning, low noise, and high output. The machine is made of stainless steel with high quality. There is no dust during the pulverizing.
Technical Data:
| Model | Main Structural Dimensions(mm) | Capacity | Input Particle Size | Output Particle Size | Machine weight | Speed | Total power | |||
| L | W | H1 | H2 | Kg/H | mm | mesh | Kg | Rpm/min | KW | |
| JB-20B | 1250 | 600 | 1500 | 1750 | 20-150 | <6 | 12-120 | 350 | 4650 | 5.1 |
| JB-30B | 1250 | 600 | 1600 | 1750 | 30-300 | <10 | 12-120 | 450 | 3800 | 8.6 |
| JB-40B | 1450 | 800 | 1650 | 1800 | 50-400 | <12 | 12-120 | 600 | 3400 | 12.1 |
| JB-50B | 1950 | 900 | 1930 | 1920 | 80-500 | <15 | 12-120 | 850 | 2900 | 19.6 |
| JB-60B | 2050 | 900 | 1930 | 2050 | 100-650 | <20 | 12-120 | 1080 | 2300 | 23.1 |
Our company locates at Wuxi city, very near Shanghai City and it only takes 30 minutes to get to our city by train from Shanghai.
1) We are golden supplier on alibaba with a history since 2008
And our factory’s history is from 2004
2) We have CE certificate, ISO,BV...etc.
3) Each year,we takes part in a lot of Expos :for example, FIC, CPHI, API...etc
1)We could do wooden package or container
2)15-35 days after receive your advanced payment
Our Service
1) our engineers are able to go abroad to install the machines
2) one year quality assurance
Guarantee against defects in materials and workmanship of equipment and parts for one year. Any parts in need of replacement will be shipped free of charge but labor for installation will not be included. Warranty does not cover abuse or user error.
3) 24-hour on line service
Any questions will be replied within 24 hours
4) Our company can agree payment by T/T, L/C,Cash.
5) Our company has our own exporting right and forwarder.
If you want to send inquriy to me about our JB Pulverizer machine ,could you please tell me?
1) What capacity you expect by one JB tea leaf mill ? (kg/h)
3) What mesh or mm or micron(size) of the powder you want?
4 ) What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...
(We only provide 3P, because our machines are all for industrial use,not for family.)
5) Usually we use stainless steel 304, if you want stainless steel 316, it's OK and please tell us.
Then our communication will be more efficient.
